Professional Automatic Lay Flat Hardcover Photobook Binding Machine

E2500 Fully automatic High speed Layflat binding machine is a fully automatic book block system which produces Lay Flat book blocks from single sheets. It can make photo book not only by gluing paper ...

  • Detailed information

      FEATURES:

      Simple operation

      State-of-the-Art software control; Visual touch screen operation panel, PLC intelligent control system

      Strong Paper compatibility

      Multiple paper channels, printing photo paper, synthetic paper, photographic paper, copperplate paper and art paper

      Speed

      Fastest speed 2500 sheets per hour

      ALL-IN-ONE Automated Design

      Pressing, Folding, Gluing, Mounting

      Flexible Range

      Max Album Size Closed :18"X18" 460mmx460mm

      Max Album Size Open :18"X36" 460mmx915mm

      Min. Album Size Closed:  6"X6" 152mmx152mm

      Min. Album Size Open:  6"X12" 152mmx305mm

      INLINE PNEUMATIC FLAT PRESSING: The machine model is complemented by an inline "Pneumatic Flat Pressing Machine" after the book block is made.


  • Specification parameters

      Key Benefits:

      l All in one system: Integrated auto feeding, gluing and assembling units;

      l Automatic paper alignment system;

      l Easy to operate via touch screen;

      l Flexible production for different sizes: 6”x6” to 18”x 18”;

      l Layflat binding technology;

      l Hotmelt gluing technology: cheaper cost and faster delivery;

      Features Book block height6”-18” ( 152mm-460mm) Book block width (open)12”-36” ( 305mm-915mm)Maximum thickness of book block50mmCardboardWith or withoutGlueHot meltThickness of cardboard0.35mm -1mmThickness of paper0.15mm-0.3mmSpeed 2500 cycles /hour Power Supply220V 50HZ Single phaseMaximum power consumption2000WMachine dimension3.06m(L) x1.15m (W) x1.38m (H)Weigh750kgAir compressor0.6-0.7mpa, >180L/min



  • Equipment functions

      FULLY AUTOMATED PRODUCTION:

      1) Automatic Paper Transfer

      2) Automatic Sandwich Transfer

      3) Automatic Creasing/Folding

      4) Automatic Gluing

      5) Automatic Rolling Back

      6) Automatic Mounting

      7) Automatic Fault Detection

      8) Automatic Double-Sheet Error Detection

      9) Automatic Inline Pneumatic Flat-Pressing
